Office building in Pennsylvania

Comcast Technology Center (Pennsylvania) by dconvertini, License CC BY-SA (https://creativecommons.org/licenses/by-sa/2.0/legalcode) *Extracted from View of Center City, Philadelphia, USA (https://www.flickr.com/photos/con4tini/51036146208/)

John Hopkins University – United States

Building use

Office building

Country/Region

All Regions

Overview

One-of-a-kind damper was adopted to withstand the height and wind horizontal loads while enabling the asymmetrical design of the building.

Basic information (construction date, number of stories, gross floor area, adopted design code, engineer(s), Contractor(s), etc.)

Construction date: 2008
Number of stories: 60
Gross floor area: 144,539m2
Adopted design code: IBC; Philadelphia Building Code; LEED 2009
Engineer(s): Thornton Tomasetti
Contractor(s): LF Driscoll

Issue and/or innovation

The building structure had to enable the asymmetrical design. The building uses a central structural concrete core and steel-framed floors. To avoid swaying, the building employs a double-chambered, concrete, 300,000 gallon liquid-tuned column damper, the largest of its kind in all of North America. Lightweight concrete (LWC) was utilized in the composite floor decks.

Reason for composite solution

To withstand the height and wind horizontal loads while enabling the asymmetrical design of the building.

Specific solution/technical details

Structural concrete core with steel-framed floors and columns.

References / Technical Papers Content

Coggin, M. (2018). Comcast Technology Center. Thornton Tomasetti. https://www.thorntontomasetti.com/project/comcast-technology-center
https://www.skyscrapercenter.com/building/comcast-technology-center/16192
